Record single-person vlogs or interviews with the Godox WEC Wireless Microphone System. The system comes with one clip-on transmitter with a built-in microphone and dual-channel receiver with a 3.5mm TRS connector. Attach the transmitter to your talent's lapel and mount the receiver to the cold shoe mount of your camera with the integrated belt clip. Use the included 3.5mm TRS and 3.5mm TRS to TRRS audio cables to connect the receiver to your camera or mobile device. The receiver and transmitter can communicate from up to 656' away via 2.4 GHz frequency.
LED indicators on the components allow you to monitor power and mode status. Onboard controls toggle between mono and stereo modes, control the ±6 dB of gain, activate noise cancellation, or pair the devices to one another. Internal rechargeable batteries power the components for up to 8 hours at a time and can be recharged using the USB-C charging ports in just 2 hours.
Features at a Glance
Specifications
- For Content Creation, Vlogging
- 1-Person Shoots with Camera or Phone
- 1 x Transmitter with Built-In Mic
- Dual-Channel Receiver
- 656' Transmission Distance
- Intelligent Noise Reduction, ± dB gain
- 3.5mm TRS Audio Output, USB-C Charging
- 3.5mm TRS to TRRS Audio Adapter Cable
- LED Indicators
| Wireless Technology |
Analog
|
| Number of RF Channel Frequencies |
2
|
| Included Transmitters |
1 x Clip-On with Microphone
|
| Diversity |
Non-Diversity
|
| RF Channel Scanning |
Auto-Scan
|
| Max Operating Range |
656.2' / 200 m
|
| Max Transmitters per Band |
2
|
| Sample Rate/Resolution |
48 kHz / 16-Bit
|
| Dynamic Range |
86 dB
|
| Receiver Type |
Camera-Mount
|
| Mounting Options |
Belt Clip (with Included Hardware)
|
| Antenna |
Internal
|
| Number of Audio Channels |
2
|
| Audio I/O |
1 x 1/8" / 3.5 mm TRS Unbalanced Output
|
| Gain Range |
-6 to 6 dB
|
| Frequency Response |
20 Hz to 20 kHz
|
| USB/Lightning Connectivity |
USB-C Female (Charging)
|
| Power Requirements |
Battery
|
| Battery Type |
1 x Built-In Rechargeable
|
| Internal Battery Capacity |
200 mAh
|
| Battery Charging Time |
2 Hours
|
| Approx. Battery Life |
8 Hours
|
| DC Input Power |
5 VDC at 200mA
|
| Display & Indicators |
LED
|
| Operating Temperature |
14 to 122°F / -10 to 50°C
|
| Dimensions |
4.8 x 2.8 x 1.5 cm
|
| Weight |
16 g
|
| Transmitter Type |
Clip-On with Microphone
|
| Auto-Level Control |
Yes
|
| Gain Range |
-6 6 dB
|
| Frequency Response |
20 Hz to 20 kHz
|
| Sync Method |
2.4 GHz QPSK
|
| Antenna |
Internal
|
| Power Requirements |
Battery
|
| Battery Type |
1 x Built-In Rechargeable
|
| Internal Battery Capacity |
140 mAh
|
| Battery Charging Time |
2 Hours
|
| Approx. Battery Life |
8 Hours
|
| USB/Lightning I/O |
USB-C (Charging)
|
| Display & Indicators |
LED
|
| Operating Temperature |
14 to 122°F / -10 to 50°C
|
| Dimensions |
4.8 x 2.2 x 1.6 cm
|
| Weight |
12 g
|
| Microphone Type |
Integrated
|
| Sound Field |
Mono
|
| Polar Pattern |
Omnidirectional
|
| Frequency Range |
20 Hz to 20 kHz
|
| Maximum SPL |
110 dB SPL
|
| Dynamic Range |
86 dB
|
| Operating Temperature |
14 to 122°F / -10 to 50°C
|
What's Included
1 x Godox WEC Wireless Microphone System for Cameras and Mobile Devices (2.4 GHz)
1 x Godox WEC TX Clip-On Wireless Microphone Transmitter (2.4 GHz)
1 x Receiver
1 x Furry Windscreen
1 x USB-A to USB-C Data Cable
1 x 3.5mm TRS Audio Cable
1 x 3.5mm TRS to TRRS Audio Cable
1 x Storage Case
